2.Special anti-static belt, slip-resistant, wear-resistant.
3.Stepper motor transmission, speed adjustable.
4.Dual precision ball screw to adjust width, smooth and stable.
5. Hardened guide rail, stable and not easily deformed.
6. Photoelectric protection, sound and light alarm in case of abnormality.
7. Configure with Standard SMEMA to communicate with other machines to achieve inline operation.
8. CE certified.
Details
Specification: (All non-standard product can be customized)
|
Model ：Single rail/ dual rails |
XY-C500/D |
XY-C800/D |
XY-C1000/D |
XY-C1200/D |
|
Overall DimensionSingle rail/ dual rails |
L500×W720×H920 L500×W1050×H920
|
L800×W720×H920 L800×W1050×H920
|
L1000×W720×H920 L1000×W1050×H920
|
L1200×W720×H920 L1200×W1050×H920
|
|
PCB width size(mm) |
50～350 |
|||
|
PCB width size(mm) |
50～350Single rail/50-300 dual rails |
|||
|
Adjustment method for guide rail |
Manually adjusting or automatically adjusting (optional) |
|||
|
Supply voltage |
Single-phase AC220V/50-60HZ |
|||
|
Air Pressure |
N/A |
|||
|
Power |
200W/400W(Single rail/ dual rails) |
|||
|
Transmission height |
900±30mm |
|||
|
PCB Transport direction |
L~R（R~L One-key switch flow direction） |
|||
|
Transport speed |
1-12m/min(Adjustable) |
|||
|
Control Mode |
Push button switch or PLC+ Touch Screen (optional) |
|||
|
Dust-proof Device |
With/without Dust Cover (optional) |
|||
